Sanyo PDP-42WV1 Service Manual

-24-
Control Port Functions
61 P31/A9 L-GREEN O High:ON, LowOFF
62 VCC
63 P30/A8(/-/D7) Not used (Output: Low)
64 Vss
65 P27/A7(/D7/D6) Not used (Output: Low)
66 P26/A6(/D6/D5) Not used (Output: Low)
67 P25/A5(/D5/D4) Not used (Output: Low)
68 P24/A4(/D4/D3) Input
69 P23/A3(/D3/D2) Input
70 P22/A2(/D2/D1) Input
71 P21/A1(/D1/D0) Not used (Output: Low)
72 P20/A0(/D0/-) RESET_SW I Externai reset SW (Input) Low:Reset
73 P17/D15/INT5 FCOM O For real time clock Low:Fixed
74 P16/D14/INT4 AIRQ I For real time clock Not used (Input)
75 P15/D13/INT3 YIRQ I For real time clock
76 P14/D12 Not used (Output: Low)
77 P13/D11 FAN-LOCK1 I Fan Lock Input High:Normal, Low:Locked
78 P12/D10 PANEL-LED I Panel LED (Fail Detection)
79 P11/D9 ALARM I Panel Fail High:Normal, Low:Fail
80 P10/D8 PW_RST O PIX reset (Output) High:Reset
81 P07/D7 LINE OFF I Power OFF Detection Low:AC OFF
82 P06/D6 P-FAIL1 I 1.5V,2.5V,3.3V,5V High:Normal, Low:Fail
83 P05/D5 P-FAIL2 I 9V,12,13V High:Normal, Low:Fail
84 P04/D4 P-FAIL3 I For Audio AMP IC High:Fail, Low:Normal
85 P03/D3 P-FAIL4 I For Option Board (Slot) High:Normal, Low:Fail
86 P02/D2 PDPGO_5 O Panel ON/OFF High:ON, Low:OFF
87 P01/D1 PWRSW I Power SW
88 P00/D0 FAN-LOCK2 I Fan Lock Input High:Normal, Low:Locked
89 P107/AN7/KI3 Not used (Output: Low)
90 P106/AN6/KI2 Not used (Output: Low)
91 P105/AN5/KI1 Not used (Output: Low)
92 P104/AN4/KI0 T-SENSOR1 I Temp-Sensor (Analog input) A/D
93 P103/AN3 T-SENSOR2 I Temp-Sensor (Analog input) A/D
94 P102/AN2 Not used (Output: Low)
95 P101/AN1 KEY-IN I Key Input A/D
96 AVSS Not used (Output: Low)
97 P100/AN0 Not used (Output: Low)
98 VREF Not used (Output: Low)
99 AVcc Not used (Output: Low)
100 P97/ADTRG/SIN4 RTC_DATA I For real time clock
Pin NO. Pin Name Signal Name I/O Note Data
