-12-
■ Adjustment
Not designated PC AV Component
76 1. Fan driving voltage adjustment ●
94 1. Fan driving voltage adjustment ●
22 2. PSIG adjustment ●
23 2. PSIG adjustment ●
1 3. Signal center DC adjustment-Red ●
2 3. Signal center DC adjustment-Green ●
3 3. Signal center DC adjustment-Blue ●
4 4. Red Sub Gain adjustment ●● ●
5 4. Green Sub Gain adjustment ●● ●
6 4. Blue Sub Gain adjustment ●● ●
13 5. Red Gain adjustment ●●
14 5. Green Gain adjustment ●●
15 5. Blue Gain adjustment ●●
11 6. 50% Luminance adjustment ●●
19 7. Flicker reduction -Red ●
20 7. Flicker reduction -Green ●
21 7. Flicker reduction -Blue ●
17 8. White balance adjustment-Red ●●
18 8. White balance adjustment-Blue ●●
Caution :
Other adjustment items are not related to service and a maintenance. Don't press the VOLUME (+) and (-) button
at the time of those adjustment items. Otherwise it may cause loss of product safety.
Item-no. Adjustment Item
Adjustment Mode
■ SERVICE MODE ADJUSTMENT MENU
