-41-
5us/Div
2ms/Div
TP_2561
TP_2571
PSIG
5V/Div
TP_2527
G 5V/Div
5V/Div
TP_2526
G 5V/Div
Input_signal
NTSC 0.5V/Div
TP_32V1
V_sync 5V/Div
Timing chart
Red LCD panel drive signal
Green LCD panel drive signal
Blue LCD panel drive signal
