Sanyo PLC-XF45 - CONNECTING PROJECTOR; Connecting to Video Equipment

15
CONNECTING PROJECTOR
CONNECTING TO VIDEO EQUIPMENT
ANALOG RGB
R/Pr G/Y B/Pb H/HV V
CONTROL PORT
DVI
INPUT 1
R/C JACK
USB
RESET
(MONO)
(MONO)
(MONO)
(MONO)
(MONO)
CONTROL PORT
AUDIO
CONTROL PORT
S-VIDEO
VIDEO/Y
C
INPUT 2INPUT 3INPUT 4
AUDIO
AUDIO
AUDIO
SERIAL PORT IN
SERIAL PORT OUT
AUDIO OUT
R
L
R
L
R
L
R
R
L
L
Video Source (example)
Video Cassette Recorder
Video Disc Player
Video
Cable ✽
S-VIDEO
Cable ✽
Audio Amplifier
Audio Speaker (stereo)
Audio Cable
(Stereo) ✽
S-VIDEO Output
Audio Input
Cables used for connection
• Video Cable (BNC x 1, BNC x 2 or BNC x 3) ✽
• S-VIDEO Cable ✽
• Audio Cable (RCA x 2) ✽
(✽ = Cables are not supplied with this projector.)
NOTE :
When connecting cable, power cords of both a
projector and external equipment should be
disconnected from AC outlet. Turn a projector
and peripheral equipment on before computer is
switched on.
Audio Output
Y
Pb/Cb
Pr/Cr
R
L
External Audio Equipment
AV AUDIO IN
S-VIDEO
Pr/Cr-Y-Pb/Cb
VIDEO
AUDIO OUT
Component video output equipment.
(such as DVD player or
high-definition TV source.)
Composite
Video Output
Component Video Output
Audio Cable
(Stereo) ✽
Video
Cable ✽
Video
Cable ✽
Separate Y/C
Video Output
Y
C
Y-C
Terminals of
a Projector
