-45-
Electrical Adjustments
Group/
Item
Item Name Function Initial Range Note
7 DIMMER_CTRL_LEVEL8
Luminance Level 8 Data for Dimmer:
Dim Level 8 at the less than the Value
56 0-255
8 DIMMER_CTRL_LEVEL9
Luminance Level 9 Data for Dimmer:
Dim Level 9 at the less than the Value
63 0-255
9 DIMMER_CTRL_LEVEL10
Luminance Level 10 Data for Dimmer:
Dim Level 10 at the less than the
Value
70 0-255
10 DIMMER_CTRL_LEVEL11
Luminance Level 11 Data for Dimmer:
Dim Level 11 at the less than the
Value
77 0 - 255
11 DIMMER_CTRL_LEVEL12
Luminance Level 12 Data for Dimmer:
Dim Level 12 at the less than the
Value
84 0 - 255
12 DIMMER_CTRL_LEVEL13
Luminance Level 13 Data for Dimmer:
Dim Level 13 at the less than the
Value
91 0 - 255
13 DIMMER_CTRL_LEVEL14
Luminance Level 14 Data for Dimmer:
Dim Level 14 at the less than the
Value
98 0 - 255
14 DIMMER_CTRL_LEVEL15
Luminance Level 15 Data for Dimmer:
Dim Level 15 at the less than the
Value
105 0 - 255
15
DIMMER_AVERAGE_POINT
Luminance Data Avarage Point for
Mimmer
4 0 - 16
16 DIMMER_AVERAGE_DATA
Luminance Data Avarage Value for
Dimmer
- - * Read only
17 DIMMER_LEVEL_AUTO Current Dimmer Leverl - - * Read only
18 DIMMER_LEVEL_NORMAL Normal Dimmer Level 7/11/11 0 - 15
19 DIMMER_LEVEL_ECO Eco Dimmer Level 0 0 - 15
20 Lamp check enable 0
0: Lamp Failure Detection OFF
(White 50% Back), 1 : ON (Blue
100% Back)
21 VOLTAGE_LEVEL Lamp Voltage - Unit: 8bit(Raw Data) * Read only
22 DIMMER_LEVEL_HIGH Dimmer level High 15 0 - 15
23 Past Calculation System - -
24 New APL System - -
25 Red Average Level - -
26 Green Average Level - -
27 Blue Average Level - -
29 SAT - -
29 Chroma Coefficient 160 0-255
Group
231
VBI Slice Level
0 Generic Initial Slicing Level PW190 register 0xE344 0x34 0-255
1
Generic High Level Thresh-
old
PW190 register 0xE345 -- 0-255
2 Generic Low Level Threshold PW190 register 0xE346 -- 0-255
3 Generic Minimum Low Level PW190 register 0xE347 0x30 0-255
4 Generic Maximum High Level PW190 register 0xE348 0xe0 0-255
Group
250
FAN Control
0 FAN1 MIN ADJUST (DAC)
DAC Output for Fan
Adjust the tolerance of DAC and Fan
Volage.
* Lamp mode is forced Eco
38 0 - 255
1 FAN1 MAX ADJUST (DAC) 233 0 - 255
2 FAN2 MIN ADJUST (DAC) 38 0 - 255
3 FAN2 MAX ADJUST (DAC) 230 0 - 255
4 FAN3 MIN ADJUST (DAC) 18 0-255
5 FAN3 MAX ADJUST (DAC) 240 0-255
6 Not used
7 Not used
8 Href 1300 0 - 9999
9 Vref 300 0 - 999
Group
251
Not used
Group
252
FAN Option
0 HI-LAND SWITCH
0: Normal, 1: Hi-Land, 2-4: Hi-Land
1-3
0 0 - 5
1 SAFETY SWITCH For test purpose 0 0 - 6
2 FAN MANUAL SWITCH 0: Auto, 1: Manual 0 0 - 3
3 FAN1 MANUAL VOLTAGE
Fan Voltage (unit : 0.1V)
Effective only when Fan Manual
switch is 1
100 0 - 255
4 FAN2 MANUAL VOLTAGE 100 0 - 255
5 FAN3 MANUAL VOLTAGE 100 0 - 255
