Electrical Adjustment
Group/
Item
Item Name Function Initial Range Note
4 Fan2 Manual Voltage * Effective only Fan Manual Switch = 1 0-255
5 Fan3 Manual Voltage 0-255
6 Fan4 Manual Voltage 0-255
Group 253 Fan Tem Error Setting (Memorized) Normal Ceiling L1 L2
0 Temp A Warning (High)
Temp. A to judge the Temp Error at HighLand
(Room)
45 45 45 45 30-100
L1
160°
200°
20°
340°
(-20°)
(-160°)
L2
Normal Ceiling
Off L1 L2
Off Normal Up Down
On Ceiling Up Down
Slant
Ceiling
Definition of Slant
Off -20° ~ 20°
L1 20° ~ 160°
L2 -20° ~ -160°
1 Temp B Warning (High)
Temp. A to judge the Temp Error at HighLand
(Lamp)
66 66 66 66 30-100
2 Temp C Warning (High)
Temp. A to judge the Temp Error at HighLand
(Panel)
49 49 49 49 30-100
3 Temp B-A Warning (High)
Temp. B-A to judge the Temp Error at High-
Land (Clogging Det.)
100 100 100 100 0-100
4 Temp C-A Warning (High)
Temp. C-A to judge the Temp Error at High-
Land (Clogging Det.)
100 100 100 100 0-100
5 Temp A Warning (Normal)
Temp. A to judge the Temp Error at Normal
(Room)
45 45 45 45 30-100
6 Temp B Warning (Normal)
Temp. A to judge the Temp Error at Normal
(Lamp)
69 69 69 69 30-100
7 Temp C Warning (Normal)
Temp. A to judge the Temp Error at Normal
(Panel)
49 49 49 49 30-100
8 Temp B-A Warning (Normal)
Temp. B-A to judge the Temp Error at Normal
(Clogging Det.)
100 100 100 100 0-100
9 Temp C-A Warning (Normal)
Temp. C-A to judge the Temp Error at Normal
(Clogging Det.)
100 100 100 100 0-100
10 Temp A Warning (Eco) Temp. A to judge the Temp Error at Eco (Room) 45 45 45 45 30-100
11 Temp B Warning (Eco) Temp. A to judge the Temp Error at Eco (Lamp) 72 72 72 72 30-100
12 Temp C Warning (Eco) Temp. A to judge the Temp Error at Eco (Panel) 49 49 49 49 30-100
13 Temp B-A Warning (Eco)
Temp. B-A to judge the Temp Error at Normal
(Clogging Det.)
100 100 100 100 0-100
14 Temp C-A Warning (Eco)
Temp. C-A to judge the Temp Error at Normal
(Clogging Det.)
100 100 100 100 0-100
15 Temp A Warning Offset (Temp)
Offset of Temp Error (Temp.)
Error Setting Value is increased XC at the
below condition
* Standby
* Right to turn on the lamp
*Right to change the Lamp mode
20 0-100
16 Temp B Warning Offset (Temp) 20 0-100
17 Temp C Warning Offset (Temp) 20 0-100
18 Temp B-A Warning Offset (Temp) 20 0-100
19 Temp C-A Warning Offset (Temp) 20 0-100
20 Temp A Warning Offset (Time)
Offset of Temp Error (Minutes)
Error Setting Value is increased X minute at
the below condition
* Standby
* Right to turn on the lamp
*Right to change the Lamp mode
5 0-5
21 Temp B Warning Offset (Time) 5 0-5
22 Temp C Warning Offset (Time) 5 0-5
23 Temp B-A Warning Offset (Time) 5 0-5
24 Temp C-A Warning Offset (Time) 5 0-5
Group 254 Fan Control Range Setting (Temp./REV) Normal Ceiling L1 L2
0 High Fan Control Min Temp
Temp Senser Control Start/End Tem.p at
HighLand
25 25 25 25 20-100
L1
160°
200°
20°
340°
(-20°)
(-160°)
L2
Normal Ceiling
Off L1 L2
Off Normal Up Down
On Ceiling Up Down
Slant
Ceiling
Definition of Slant
Off -20° ~ 20°
L1 20° ~ 160°
L2 -20° ~ -160°
1 High Fan Control Max Temp 34 34 34 34 20-100
2 High Fan1 Min
Fan Operation REV(Min/Max) setting at
HighLand (rpm)
1960 1960 1960 1960 0000-9990
3 High Fan1 Max 2420 2420 2420 2420 0000-9990
4 High Fan2 Min 1800 1800 1935 1935 0000-9990
5 High Fan2 Max 2550 2550 2550 2550 0000-9990
6 High Fan3 Min 3620 3620 4600 3620 0000-9990
7 High Fan3 Max 4600 4600 5350 4600 0000-9990
8 High Fan4 Min 2690 2690 2690 2690 0000-9990
9 High Fan4 Max 4855 4855 4855 4855 0000-9990
10 Normal Fan Control Min Temp
Temp Senser Control Start/End Tem.p at
Normal
25 252 25 25 20-100
11 Normal Fan Control Max Temp 34 34 34 34 20-100
12 Normal Fan1 Min
Fan Operation REV(Min/Max) setting at
Normal (rpm)
1760 1760 1760 1760 0000-9990
13 Normal Fan1 Max 2200 2200 2200 2200 0000-9990
14 Normal Fan2 Min 1625 1625 1760 1760 0000-9990
15 Normal Fan2 Max 2245 2245 2245 2245 0000-9990
16 Normal Fan3 Min 3190 3190 4110 3190 0000-9990
17 Normal Fan3 Max 4110 4110 4975 4110 0000-9990
18 Normal Fan4 Min 2360 2360 2360 2360 0000-9990
19 Normal Fan4 Max 4705 4705 4705 4705 0000-9990
20 Eco Fan Control Min Temp
Temp Senser Control Start/End Tem.p at Eco
25 25 25 25 20-100
21 Eco Fan Control Max Temp 34 34 34 34 20-100
22 Eco Fan1 Min
Fan Operation REV(Min/Max) setting at Eco
(rpm)
1560 1560 1560 1560 0000-9990
23 Eco Fan1 Max 1975 1975 1975 1975 0000-9990
24 Eco Fan2 Min 1450 1450 1580 1580 0000-9990
25 Eco Fan2 Max 1935 1935 1935 1935 0000-9990
26 Eco Fan3 Min 2760 2760 3620 2760 0000-9990
27 Eco Fan3 Max 3860 3860 4600 3620 0000-9990
28 Eco Fan4 Min 2025 2025 2025 2025 0000-9990
29 Eco Fan4 Max 4550 4550 4550 4550 0000-9990
