Sanyo PLC-XU301 Service Manual

Key No. Part No. Description Key No. Part No. Description
KD5-XU30100
Electrical Parts List
-88-
RESISTOR
R2901 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2903 301 224 8814 MT-GLAZE 100 JA 1/16W
R8831 301 225 8110 MT-GLAZE 10 JA 1/16W
R8832 301 225 8110 MT-GLAZE 10 JA 1/16W
MISCELLANEOUS
A2901 652 002 3352 UNIT,REMOCON,RECEIVER
SC2091 945 076 3503 SURGE-ABSORBER
SC2092 945 076 3503 SURGE-ABSORBER
655 002 9669 ASSY,PWB,ID CONNECT-1 KD5AC
RESISTOR
R8738 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
COIL
L8731 945 086 6037 IMPEDANCE,330 OHM P
L8732 945 086 6037 IMPEDANCE,330 OHM P
L8733 945 086 6037 IMPEDANCE,330 OHM P
L8734 945 086 6037 IMPEDANCE,330 OHM P
L8737 945 086 6037 IMPEDANCE,330 OHM P
CAPACITOR
C8741 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
C8742 303 155 1612 CERAMIC 33P J 50V
C8743 303 155 1612 CERAMIC 33P J 50V
C8744 303 155 1612 CERAMIC 33P J 50V
RESISTOR
R8744 301 224 8814 MT-GLAZE 100 JA 1/16W
R8749 301 224 8814 MT-GLAZE 100 JA 1/16W
R8753 301 224 9019 MT-GLAZE 10K JA 1/16W
R8756 301 224 8814 MT-GLAZE 100 JA 1/16W
R8757 301 224 8814 MT-GLAZE 100 JA 1/16W
R8759 301 225 1210 MT-GLAZE 4.7K JA 1/16W
R8760 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R8761 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
PACKING MATERIALS
610 344 9586 CARTON CASE-KD5AC
610 340 0297 POLY BAG-KB3AC
610 344 5762 CUSHION SPACER-KG5AC
610 343 1659 CUSHION TOP-KG5AC
610 343 1642 CUSHION BTM-KG5AC
ACCESSORIES
OWNER'S MANUAL
610 343 6456 CD-ROM(PJ NW MANAGER)
610 344 5175 CD-ROM,OWNERS MANUAL-KD5AC
655 002 9614 SETUP INST-KD5AC
655 003 0641 SAFETY MANUAL-KG5AC
REMOTE CONTROL
645 099 3213 ASSY,REMOCON CXZR
610 344 9944 RC-BATTERY LID-MXAC
AC CORD
!US 645 093 3028 CORD,POWER-2.3MK,US
!EU 645 093 2984 CORD,POWER-2.3MK,EU
!UK 645 093 3004 CORD,POWER-2.3MK,UK
MISCELLANEOUS
610 343 0249 STRAP CAP-KT7AC
610 342 8024 CARRY BAG-KL6A
945 073 4855 CABLE,INTERFACE VGA
645 093 1642 CABLE,INTERFACE VGA
