Sanyo PLV-Z800 User Manual

A9
PCB_MF4AE
Printed Wiring Board Diagrams
FILTER (SIDE: A)
TYPE: 215005 T5AH250V
(LIVE)
1AA4B10C5980A_A
PARTS_SIDE
? ? ?
* * *
F601
1
2
3
R611
L611
C611
L612
C612
C613
K6A
VA612
VA613
C617
C618
SW601
C614
C616
K601
VA611
A30C5
FILTER (SIDE: B)
SOLDER_SIDE
F601
3
2
1
R611
L611
C611
L612
C612
C613
K6A
VA612
VA613
C617
C618
SW601
C614
C616
K601
VA611
A30C5
SW902
DOOR SW 1 (SIDE: A)
DOOR SW 1 (SIDE: B)
PARTS_SIDE
1
3
K8801
SW8801
A30C5
SOLDER_SIDE
3 1
K8801
SW8801
A30C5
MAIN
“K8M”
DOOR SW 2 (SIDE: A)
PARTS_SIDE
SW8811
1
3
K8811
A30C5
MAIN
“K8L”
DOOR SW 2 (SIDE: B)
SOLDER_SIDE
SW8811
3
1
K8811
A30C5
! CAUTION
This projector is isolated from AC line by using the internal converter transformer.
Please pay attention to the following notes in servicing
1. Do not touch the part on hot side (primary circuit) or both parts on hot and cold
sides (secondary circuit) at the same time.
2. Do not shorten the circuit between hot and cold sides.
3. The grounding lead must be connected to the ground of the same circuit when
measuring of voltages and waveforms.
ECO
POWER
“K19A”

Sanyo PLV-Z800 Specifications

General

Resolution	1920 x 1080
Lamp Life	2000 hours (Normal Mode), 3000 hours (Eco Mode)
Lens Shift	Vertical: ±100%, Horizontal: ±50%
Projection Size	40 - 300 inches
Brightness	1200 ANSI lumens
Contrast Ratio	15000:1
Zoom Ratio	2x
Inputs	HDMI, Component, Composite, S-Video
Display Technology	3LCD
