Controller PCB
Part No. —
Controls —
Control circuit fuse —
Remote Control Unit —
Compressor
Type Rotary (Hermetic)
Compressor model 2P17C225AND
Source 240V Single phase 50Hz
Nominal output W 920
Compressor oil ... Amount cc ATMOS M60 or SUNISO 4GDID ... 350
Coil resistance (Ambient temp. 25°C) Ω C–R : 3.61
C–S : 4.97
Safety devices Type External protector
Overload relay MRA98776
Operating temp. Open °C Automatic opening
Close °C
Automatic reclosing
Operating amp.(Ambient temp. 25°C) —
Run capacitor µF 25
VAC 400
Fan & Fan Motor Indoor Outdoor
Type Centrifugal Propeller
Dia. / Depth mm ø180 / D85 ø285 / D90.7
Fan motor model ... Q'ty YSK45-4A/K ... 1
Source 240V Single phase 50Hz
No. of poles ... rpm (240 V, High) 4 ... 1,030
Nominal output W 40
Coil resistance (Ambient temp. 20°C) Ω WHT-BRN : 212
WHT-VLT : 52
VLT-YEL : 13
YEL-RED(PNK) : 119
Safety devices Type Internal protector
Operating temp. Open °C 135
Close °C Automatic reclosing
Run capacitor µF 3.5
VAC 440
Heat Exch. Coil
Coil Evaporator Condenser
Rows 3 3
Fin pitch mm 1.4 1.8
Face area
