Control of Mini ECO-i SYSTEM
7. Remote Sensor
No. Q’ty
1
2
2
3 2
Machine screws
M4 × 25 mm
4
2
5
2
7
6
1
1
1
Spacers
Wire joints
Remote sensor
Installation manual
(comes with 200 mm wire)
Place of installation
•Mount the remote sensor at a height of 1 to 1.5 meters above the floor
where it can sense the average temperature of the room.
• Do not mount the remote sensor in a place exposed to direct sunlight or a place
exposed to outside air such as near a window.
• Do not mount the remote sensor behind an object so that it is separated from the
air circulation of the room.
•Mount the remote sensor within the room being air conditioned.
• The remote sensor must be moun
ted on the wall or other surface vertically.
Supplied parts
Clamp
Wood screws
I Remote Sensor Installation Guidelines
Remote Sensor / ART-K45AG
I Parts Supplied with Remote Sensor
