4
4 - 136
Mini ECO-i SYSTEM Unit Specifications
9. Floor-Standing Type (F Type)
9-1. Specifications
Unit specifications (A)
MODEL No.
Indoor Unit
SPW-FR74GXH56(A/B)
POWER SOURCE
220 - 230 - 240 V / Single-phase / 50 Hz
PERFORMANCE Cooling Heating
Capacity kW
2.2
2.5
BTU / h 7,500
8,500
Air circulation (Hi / Me / Lo) m
3
/h 420 / 360 / 300
Moisture removal (High) Liters/h
1.0
–
ELECTRICAL RATINGS
Voltage rating 240 220 230
240
Available voltage range
198 – 264
198 – 264
Running amperes A
V
V
0.24 0.25 0.26 0.17
0.18
0.19
Power input W 51 56 61 36 40
45
Power factor % 97 97 98 96 97
99
Max. starting amperes
A
11 1 11
1
FEATURES
Controls
Microprocessor
Timer ON / OFF Timer (Max. 72 hr)
Fan speeds
3 and Automatic control
Air filter
Washable, easy access
Refrigerant control
Electronic expansion valve
Operation sound (Hi / Me / Lo) dB-A
33 / 30 / 28
Refrigerant tubing connections
Flare type
Refrigerant tube diameter Liquid tube mm (in.)
6.35 (1/4)
Gas tube mm (in.)
12.7 (1/2)
Drain connection 20A, OD26 mm
Remote controller
Optional (RCS-SH80AG)
Refrigerant tubing kit / Accessories
Optional / –
Color (Approximate value)
Munsell 10Y 9.3 / 0.4, RAL 9010-GL
DIMENSIONS & WEIGHT
Package dimensionsUnit dimensions
Unit dimensions
Height mm (in.)
615 (24-7/32) 694 (27-10/32)
1157 (45-18/32)
312 (12-9/32)
0.251 (8.9)
Width mm (in.)
1065 (41-30/32)
Depth mm (in.)
230 (9-2/32)
Net weight
kg (lbs.)
Shipping weight kg (lbs.)
Shipping volume m
3
(cu. ft)
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Rated conditions
Cooling: Indoor air temperature 27°C DB / 19°C WB; Outdoor air temperature 35°C DB
Heatin
: Indoor air temperature 20°C DB; Outdoor air temperature 7°C DB / 6°C WB
220
230
29 (64)
31 (68)
06-405 Mini-ECOi_TD4 11/8/06 4:28 PM Page 136
