4
4 - 122
Mini ECO-i SYSTEM Unit Specifications
7. Concealed Duct Type (U Type)
Indoor unit: 36, 48 Type
Refrigerant liquid line ø9.52 (liquid tube)
Refrigerant gas line ø15.88 (gas tube)
Upper drain port (O.D. 32 mm)
Bottom drain port (O.D. 26 mm)
Suspension lug
Power supply outlet (2-ø30)
Fresh air intake port (ø150)
Flange for the flexible air outlet duct (ø200)
Tube cover
Electrical component box
Flange for the air intake duct
(Option or field supply)
9
10
11
(Suspension bolt pitch)
18-ø3.3
(Hole)
1442 (Air outlet duct flange)
230 P
×
6 = 1380
1480
1560 (Suspension bolt pitch)
(150)
40
335 335 335 310 75
65
90
230
3131
185
580
25
115
19
Inspection access
(450 × 450)
(Field supply)
10
285
70 130
25 210
310
25
175
35
190
85
25
7030
160
630
25
10
11
24
260
(Air outlet
duct flange)
06-405 Mini-ECOi_TD4 11/8/06 4:28 PM Page 122
