Preparing for the Dual-Faced Installation
The mounting pole has been designed to be installed on a double gang box, which will hold the mounting
pole and the dual-faced clocks. As such, to install a dual-faced clock, there is a need to have the double
gang box fixated and secured to the ceiling and/or to the wall and have the network cable pre-wired and
ready to be connected to the clock.
If any of the items listed in the kit are missing, you may contact your dealer and order a replacement kit.
Dual-Faced / Flag Mounted Clock Mechanical Installation
#6-19x7/16 Phillips round head
black screw (not used in this
configuration)
#6-32x5/16 Phillips round head
silver screw (not used in this
configuration)
#6 Internal-tooth lock washer
(not used in this configuration)
10
6
6
If not mounting the clock to a double gang box, the installer needs to provide:
#8 self-tapping screws
Wall anchors
4
4
