61
– Enter the desired maximum capacity (in this example, 30.0 kg; key sequence:
k k k k ) k ) p ) k) and then press and hold )
(> 2 sec) to store the value. Enter “30” (it is not necessary to enter the decimal
point and the last “0”).
After you store the data, the program jumps back to menu item 11-4-4.
Note: If “Multiple-range scale” or “Multi-interval scale” was selected during A/D
converter configuration rather than “Single-range scale”, then the range limits
must be entered under menu line 11-5 (multiple-range) or 11-6 (multi-interval).
Each of these menu lines has 3 items to choose (range limits 1, 2 and 3).
– Store the configuration data: Select menu line 11-10 (key sequence: ( k
k k
– Press ) to open menu item 11-10-2 (“Do not store configuration”)
(active setting).
– Press k to select menu item 11-10-1 (Store configuration).
Display_Serv_1144.eps
display_serv_1110.eps
Display_Serv_11102.eps
Display_Serv_11101.eps
standard1Ib.eps
