Data output example: +123.56 g
Position 12345678901234
+ 123 . 56 g CRLF
+ 123.5[6]g CRLF
Position 1: Plus or minus sign or space
Position 2: Space
Positions 3-10: Weight with a decimal point; leading zeros = space
Position 11: Space
Positions 12-14: Unit symbol or space
Position 15: Carriage return
Position 16: Line feed
Output Format with 22 Characters
When data is output with an ID code, the ID code (consisting of 6 characters) precedes the
16-character string described above.
These 6 characters identify the subsequent value.
12345678910111213141516171819202122
IIIIII+*DDDDDDDD * UUUCRLF
*****– ........ ***
* ********
I: ID code character U: Unit symbol
1
)
*: Space CR: Carriage return
D: Digit or letter LF: Line feed
Example:
12345678901234567890
N + 123 . 56 g CRLF
N + 123 . 5[6 ] g CRLF
1
) depends on balance type; for example, not all units or characters are available on balances
verified for use in legal metrology.
52
