Data Input Format
You can connect a computer to your balance to send commands via the balance interface
port to control balance functions and applications.
The commands sent are control commands and may have different formats.
Control commands consist of up to 13 characters. Each character must be transmitted
according to the settings configured in the operating menu for data transmission.
Format for Control Commands
Format 1: Esc ! CR LF
Format 2: Esc ! # _ CR LF
Esc: Escape CR: Carriage return (optional)
!: Command character LF: Line feed (optional)
Command character Format 1:
! Meaning
K Weighing mode 1 (very stable conditions)
L Weighing mode 2 (stable conditions)
M Weighing mode 3 (unstable conditions)
N Weighing mode 4 (very unstable conditions)
O Block keys
P r key (print, auto print; activate or block)
R Unblock keys
S Restart/self-test
T w key
Z Internal calibration/adjustment
Command character Format 2:
!# Meaning
f0 Function key v
f1 Function key q
s3 c key
x0 Perform internal calibration
x1 Print balance model
x2 Print weighing cell serial number
54
