Below-Cell Weighing
A port for a below-cell weighing hook is located on the bottom of the weigh cell
(not model WZA54-L).
Models WZA224-L, WZA224-LC and WZA523-L:
§ Carefully install the customer-specific hook.
Threaded fastener for hook: M3
Maximum torque: 0.8 Nm. Overload protection available.
! Maximum screw installation depth: do not exceed 5 mm!
Otherwise no underweight protection.
Model WZA8202-L:
§ Hang below-cell weighing hook in the holder or screw into the M3 thread next to it.
! Model WZA8202-L: no overload and underweight protection available.
$ Install a draft shield if necessary.
WZA224-L, WZA224-LC, WZA523-L:
WZA8202-L:
10
