24
Data Output Format with 16 Characters
Characters that are displayed blank are printed as spaces. Display values without a decimal
point are output without a decimal point.
The type of character that can be output depends on the character‘s position:
Normal Operation
Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
+ A A A A A A A A A * E E E CR LF
or – . . . . . . . . . * * *
or * * * * * * * * * *
*: Space
A: Digits of measurement value
E: Unit symbol
CR: Carriage return
LF: Line feed
Once command »ESC s9_« has been
sent, data input and data output beha-
ve as in the earlier Sartorius WZ-/WZA
weigh cells (previous models).
Data Output Format
In operating mode »SBI«,
16 characters are printed out.
Example:
+ 253 pcs
Data Interface:
Compatibility with Older Weigh Cells (Previous Models)
