30
Overview
Specifications
Standard specifications Customer-specific
modifications
Model WZA224-LC WZA224-L WZA54-L WZA523-L WZA8202-L
Technology EMFR EMFR EMK EMFR EMFR
Weighing Capacity g 220 220 50 520 8200
Readability g 0.0001 0.0001 0.0001 0.001 0.01
Required preload on the load receptor g 10 10 5 30 350
Tare range (subtractive) g over entire weighing range
Repeatability (standard deviation)
1
) <±g 0.0001 0.0001 0.0002 0.001 0.01
Linearity <±g 0.0002 0.0002 0.0005 0.002 0.02
Measurement time
3
) s 0.6 0.6 0.8 0.6 0.6
Adaptation to ambient conditions By selection of 1 of 4 optimized filter levels
Operating temperature range °C +10…+30 °C
Allowable ambient operating temperature °C +5…+40 °C
Sensitivity drift within +10… +30 °C <±/K 1 · 10
-6
1 · 10
-6
1 . 10
-6
2 · 10
-6
2 · 10
-6
External calibration weight g 50 (E2) 50 (E2) 10 (E2) 200 (F1) 2000 (F1)
(min accuracy class)
Net weight, approx. kg 2.2 1.15 0.62 1.15 1.15
Power supply VDc min. 12 … 26 max., optimal 15 V (+15% to –10%)
Ripple 50/60 Hz VDc 0.5 Vpp (voltage peak-to-peak)
Power consumption 3.4 W average
Switch-on current 6 W average (weigh cell only)
Built-in interface RS-232C-S/V24-V28; 7-bit; even, mark, odd, space;
Transmission rates: 150 to 19200 baud,1 or 2 stop bits; software/hardware handshake
1
) = Depends on system design
2
) = For operation with greater preload setting, please send e-mail to request PC configuration software; e-mail address: fast.factory@sartorius.com
Greater preloads are possible, but reduce the weighing capacity.
3
) = The weighing time is the time period in which the measured value oscillates within a range of ±3x the standard range of the static end value.
Test weight approx. 25% of max.
