Maintenance
Replacing the Paper Roll
The paper rolls used with your data printer must have
the following specifications (see “Accessories”):
– Standard paper roll
– Wood-free paper, 60 g
– Width: 57.5 ± 0.5 mm
– Diameter: Max. 65 mm
– Core diameter: Min. 8 mm
§ Lift the cover of the paper roll compartment
§ Pull out the roll holders from both sides of the roll core
as shown on the left
§ Remove the old roll core
$ Place a new paper roll on a flat surface
$ The open end must be on the bottom of the roll and
facing the front of the printer
§ Hold the paper roll above the paper roll compartment
between thumb and index finger of one hand
§ Thread the paper through the slot underneath the ink
ribbon with your other hand
§ To transport the paper through the ink ribbon cassette,
press the key repeatedly, or hold it down
> The paper will be threaded into, then out of the ink
ribbon cassette
10
