8. "
ΩVmA " Terminal
This terminal is a plug-in connector for the red test lead for all measurements except temperature
measurements and the current measurements * 200mA. It is also a plug-in connector for the positive
(+) plug of the K type thermocouple for temperature measurements.
9. Illumination Button
Press and hold down this button to turn on the illumination lamp. To turn off the illumination lamp,
just release this button.
10. AC Voltage Detection Indicator
11. " H " Button
Used to enter/exit Data Hold mode.
12. Holster
13. Illumination Lamp
