SatLab SL700 GNSS RTK - Overall Appearance; Upper Cover

Product Introduction
6
2.1 Overall appearance
The product appearance is divided into three parts, including the upper cover, bottom cover and
control panel.
Figure 2-1-1Front
2.1.1 Upper cover
Figure 2-1-2Upper Cover
Anti-wear Buffer: Wear prevention points can enable the host to avoid scratching.
Control panel
Upper cover
Bottom cover
Anti-wear Buffer
