SL700 GNSS RTK System Getting Started
29
Figure 4-4-1Benchmark
4.5Battery & charger
4.5.1 Battery installation and unload
1. Installation
Press the battery cover button gently and press down. The battery cover can be lifted upwards.
The battery cover and battery are removed as shown in the figure. To the right is unlocked and
locked to the left.
130mm
95.45mm
(phase center)
Benchmark
