SL700 GNSS RTK System Getting Started
7
2.1.2Bottom cover
Figure 2-1-3 Bottom Cover
- Connection screw: For fixing the instrumentto the base or a pole
- Protective plug: Used for dustproof and waterproof sockets.
- Five-pin socket: For external data linking and external power supply.
- Network/ Radio antenna interface: Network antenna when using the network, radio antenna
when using the radio.
-USB socket: Connect the hostwith external devices, to upgrade firmware and download static
1.Five-pin socket&Protective plug2. Host label3. Connection screw
4. Speaker5. Battery compartment and cover6. USBsocketand protective plug
7. Network/radio antenna interface and protective plug
1
2
3
7
1
6
1
4
1
5
1
