SL700 GNSS RTK System Getting Started
33
4.5.5 Operation of charging
Figure 5-5-5 Method of Charging
1. Put the on the bottom of the battery marked with Open to the battery compartment, and
put into the battery rack.
2. Install the battery by gently pressing and pushing it toward the end marked Close.
3. When the power is connected, the charge indicator is displayed in red to start charging.
Notice: 1. Only use battery and charger configured by manufacturer, and do
not throw them into the fire or use the metallic short-circuit electrode.
2. In case of heating, deformation, liquid leakage, smell emission or
other anomaly phenomenon during the use, charging or storage period
of the battery, please stop using and replace it with new one.
3. If the service time of the battery is shortened obviously, please stop
using the battery. It indicates that the battery has been aged; please
replace it with new one.
