4.7 SIGNAL-OVER-NOISE RATIO (SNR) MONITORING
Signal over Noise Ratio monitoring records the history of SNR over time. SNR is defined as the ratio of signal power to the
noise power, often expressed in decibels, to compare the level of a desired signal to the level of background noise. A ratio
higher than 1:1 (greater than 0 dB) indicates more signal than noise.
SNR measurement over time
Drop down to list channels of
current Network profile for
Current SNR measurement value
Pause SNR monitoring
SNR measurement of current
selected channel/frequency
Sampling speed
Threshold/Limit to trigger alarm
Dropdown of Network profile for
selection
To Next Page
