4.2 Platen Roller and Front Cover.
Platen Roller
1. From upside of the printer, use screwdriver
to loosen 6 screws which are marked in
orange. Then we can take off the front
cover. (Figure B-1)
2. When we face to the printer ,taking out the
left and right bushing which are marked in
orange, then we could take out the platen
roller. (Figure B-2)
Warning:
Always turn off printer power before removal.
B-1
B-2
