Sauder 417714 - Part and Hardware Identification; Component Identification

Table of Contents Assembly Tools Required
2-4
5-6
7-48
49-54
55-60
61-62
63
Part Identifi cation
Hardware Identifi cation
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
417714 www.sauder.com/servicesPage 2
Part Identifi cation
å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts.
A OUTER RIGHT END (1)
B2 INNER RIGHT END (1)
C OUTER LEFT END (1)
D2 INNER LEFT END (1)
E RIGHT UPRIGHT (1)
F LEFT UPRIGHT (1)
G2 RIGHT TOP (1)
H2 LEFT TOP (1)
I RIGHT BOTTOM (1)
J LEFT BOTTOM (1)
K RIGHT MODESTY PANEL (1)
L LEFT MODESTY PANEL (1)
N RIGHT BACK (1)
O LEFT BACK (1)
P DOOR (1)
Q ADJUSTABLE SHELF (1)
R RIGHT LEG (1)
T LEFT LEG (1)
QQ FRONT PANEL (1)
RR RIGHT SIDE SKIRT (1)
SS LEFT SIDE SKIRT (1)
TT RIGHT BACK SKIRT (2)
UU LEFT BACK SKIRT (2)
VV KEYBOARD UPRIGHT (1)
WW KEYBOARD FRONT (1)
XX KEYBOARD BACK (1)
YY RIGHT KEYBOARD SIDE (1)
ZZ LEFT KEYBOARD SIDE (1)
AAA KEYBOARD SHELF (1)
BBB TOP RIGHT FRONT MOLDING (1)
CCC TOP LEFT FRONT MOLDING (1)
DDD REAR TOP MOLDING (1)
EEE TOP LEFT REAR MOLDING (1)
FFF TOP RIGHT SIDE MOLDING (1)
GGG TOP LEFT SIDE MOLDING (1)
HHH TOP RIGHT REAR MOLDING (1)
JJJ PLINTH (8)
LLL SPACER (2)
MMM HALF DISK (8)
M35 END MOLDING (4)
