Sauder 417714 - Hardware Identification

Hardware Identifi cation
å Screws are shown actual size. You may receive extra hardware with your unit.
417714www.sauder.com/services
Page 5
PPP
NARROW EXTENSION
RAIL - 8
QQQ
NARROW EXTENSION
SLIDE - 8
NNN
WIDE EXTENSION
RAIL - 2
OOO
WIDE EXTENSION
SLIDE - 2
LOCK - 1
1J
LOCK COVER - 1
10J
LOCK
BRACKET - 1
5J
(EXTENSION SETS SHOWN SEPARATED)
KNOB - 6
42K
FILE GLIDE - 2
6B
FILE ROD - 2
8B
TWIST-LOCK®
FASTENER - 37
7F
HIDDEN CAM - 2
1F
CAM DOWEL - 2
2F
HINGE - 2
14H
KEYBOARD
HINGE - 2
12H
MOLDING
CONNECTOR - 5
17F
CONNECTOR
PLATE - 1
14G
CORNER
BRACKET - 4
31G
ANGLE
BRACKET - 37
5G
CORD CLIP - 3
9P
LARGE DRAWER
FRONT BRACKET - 2
10G
GROMMET - 3
10P
GROMMET CAP - 3
1P
FELT DISC CARD - 1
1M
METAL PIN - 8
1R
RUBBER
SLEEVE - 4
2R
DRAWER FRONT
BRACKET - 1
9G
TOP DRAWER
FRONT BRACKET - 2
6G
