Sauder Carson Forge 416969 - Step 25: Door Adjustments; Guide for adjusting door alignment

Step Step 25
416969 www.sauder.com/servicesPae 30
å
Refer to the enlared diaram to identify the parts on
the HINGES.
å
The DOOR may need some adjustments. Follow the text
below to make needed adjustments.
å
DOOR ADJUSTMENTS:
To adjust the DOOR from side to side (horizontal), loosen the
mountin screw several turns, then turn the
adjustin screw in or out. Tihten the
mountin screw after makin adjustments.
å
To adjust the DOOR up and down (vertical), loosen both vertical
adjustment screws. Move the DOORS up or down to the desired
location. Tihten the screws after makin adjustments.
å
To adjust the DOOR in or out (depth), loosen the mountin
screw one turn and move the DOOR in or out, as needed.
Tihten the mountin screw after makin adjustments.
Adjustin screw (horizontal)
Mountin screw (depth)
(vertical adjustment)
