Sauder Carson Forge 416969 - Step 30: Attach Drawer Slides to Drawer Sides; Attach drawer slides to drawer sides

Step
416969www.sauder.com/services
Pae 35
Step 30
å
Insert a SLIDE CAM (10A) into the DRAWER SIDES (D107 and D108).
å
Fasten a DRAWER RIGHT (40CC) to one of the RIGHT DRAWER
SIDES (D107) and a DRAWER LEFT (40CD) to one of the LEFT
DRAWER SIDES (D108). Use four GOLD 5/16" FLAT HEAD
SCREWS (3S) throuh holes #1 and #4.
å
Repeat this step for the other small drawer.
1
2
3
4
Roller end
Roller end
1
2
3
4
D107
D108
Screw head - turn CAM to line up holes in
the SLIDES with holes in DRAWER SIDES
10A
10A
GOLD 5/16" FLAT HEAD SCREW
(8 used in this step)
3S
