Multistat Smart Thermostat Deployment Guide (CLI-W210x/W200x) 18 of 21 45 Perseverance Way, Hyannis MA 02601
009-1959-00 | 200723 Savant.com | 508.683.2500
Select Outdoor
Sensor
SKIP
NEXT
BACK
None
RS1
RS2
Screen Mode
SKIP
NEXT
BACK
NORMAL
ALWAYS ON
Weather Settings
WEATHER ENABLED
LOCATION
SKIP
NEXT
BACK
SKIP
ON OFF
EDIT
City, State, Zip
Scene Settings
SAVANT SCENES
SELECT HOST
Host 1
192.168.20.50
Host 2
192.168.20.60
SKIP
NEXT
BACK
SKIP
ON OFF
Select which sensor's temperature data to present
as the outdoor temperature on the thermostat's
main screen. Only RS1 or RS2 are supported when
monitoring the outdoor temperature.
None - Select None when not monitoring the
outdoor temperature.
NORMAL - By default, the thermostat's touchscreen
is o. To activate, touch the LCD screen to view the
temperature, humidity, etc. As long as the screen is
touched, it will remain active. After not touching the
screen for 30 seconds, it will go back to o.
ALWAYS ON - The touchscreen is always on. The
light level in the room determines the brightness
level on the screen.
• When the lighting level in the room is high,
the brightness of the touch screen is bright.
• As the light level in the room dims, the
brightness of the touchscreen also dims.
Example: Before going to bed, the lights in the room
are on, and the touchscreen's level of brightness
is high. Once in bed and the room is dark, the
touchscreen brightness reduces until it is very dim
so the person can sleep.
RS2 - Select RS2 when monitoring the outdoor
temperature using the sensor wired to the RS1
terminal on the thermostat's mounting plate.
ON - The weather forecast function is enabled and
displays the forecast for the week on the screen.
OFF - The weather forecast function is disabled.
ON - Global / Shared Scenes from the local Savant
Host (Select Host below) are made accessible from
the thermostat.
OFF - Scenes are not added to the thermostat.
EDIT - Select EDIT to manually change the city, state,
and zip code using the on-screen keyboard. After the
thermostat resets, the forecast for that location will
be displayed.
When connected to Wi-Fi, the location automatically
populates and is loaded into the thermostat after a
reboot. The loading of the location parameters can
take several minutes to load after a restart.
WEATHER ENABLED
SAVANT SCENES
SELECT HOST
Displays any Savant Host located on the network.
Select a Host, and the Scenes from the Host chosen
will populate to the thermostat's touchscreen.
LOCATION
Weather information for any location around the
world can be displayed on the thermostat's main
screen (Wi-Fi connection required). To enable the
feature, enter a location using the city, state, zip
code. Use the information below to edit the Weather
Settings screen.
RS1 - Select RS1 when monitoring the outdoor
temperature using the sensor wired to the RS1
terminal on the thermostat's mounting plate.
