Appendix A: HVAC Data Table Basics
The HVAC data table in Blueprint aects what functions and features are available in the Savant Pro and TrueControl II apps. Modifications made to the data
table will aect what functions and features are available in these apps. An explanation of each field in this table is described below.
1. To access the data table, open Blueprint and select Tools > Settings > HVAC.
2. Use the descriptions in the table below when making updates to the data table.
3. After changes are made, save and upload configuration file to the Host.
Enabled
Checked - An HVAC service for the row was generated in Blueprint, and an HVAC service icon got added to either the
Pro or TrueControl II app.
Unchecked - No service is generated.
Controller
Select from the drop-down menu, the thermostat that got added to the configuration. When there is more than one
thermostat in the configuration, all will be listed. When there is more than one thermostat, the Controller field associates
the thermostat with a Location from the Location field.
Location Determines which zone to add the thermostat to in the User Interface (Pro App/TrueControl II).
Entity
The Entity column only aects the TrueControl II App. Set the field to ZoneWithSingleHumidityPoint.
– ZoneWithSingleHumidity - Displays the humidity info boxes in TrueControl II
– Zone - Displays a screen without humidity.
Note: 3rd Party thermostats only support the zone selection.
Thermostat [1] Enter < 1 > for all Savant thermostats. For 3rd party thermostats, enter the address configured to the thermostat.
Thermostat [2] Not Applicable
Heat/Cool/Auto/Humidity
Checked - Adds an entity for that function to the User Interface (Pro App / TrueControl II).
Unchecked - Do not populate or remove the function from the User Interface (Pro App / TrueControl II).
Humidify Not Supported
Dehumidify Not Supported
External Temperature Sensor
Checked - Adds an external sensor entity to the User Interface (Pro App/TrueControl II).
Unchecked - Do not populate or remove the external entity from the User Interface (Pro App / TrueControl II).
HVAC Settings
Enabled Controller Location Entity Heat Cool Auto Humidity Humidify Dehumidify External Temperature Sensor State
Kitchen Tstat.HVAC_co
ThermostatAddress [1] ThermostatAddress [2]
Show Advanced Columns
Savant App Zone Map
TrueControl Zone Map
Regenerate AllEnable All
Disable All
+
Kitchen Tstat Kitchen ZoneWithHumidityPoint 1
Done
ExportImport
Cancel
?
