13
Operating from the COP Controls
Figure 2 shows the Multilift car operating panel (COP).
Figure 2
RESIDENTIAL COP
Key switch
Alarm button
PUBLIC COP
Landing buttons
Emergency stop
To operate the Multilift from the COP controls:
1 Insert the key into the key switch and turn it to the ON position to activate
the operating buttons.
2 Apply constant pressure on the UP/DOWN switch (as required) to move the
platform to the desired landing. Note that the Multilift will not move if one
of the doors /gates is open.
3 When the lift reaches the landing, the door will unlock automatically (for
units with mechanical GAL locks). For units with an interlock (WR500 or
Prolock), the door will unlock automatically for a few seconds when the lift
reaches the landing. If you need to re-open the door after the delay, turn the
key to the ON position and press the call button again to unlock the door.
Part No. 000609, 30-m01-2024 Multilift Owner’s Manual
