SCAN 64 Series - Technical Data and Dimensions

TECHNICAL DATA
4
Scan 64-1, Scan 64-3 and Scan 64-5 Technical data Unit
CO Emission at 13% O
2
0,08 %
CO Emission at 13% O
2
975 mg/Nm
3
Dust @ 13% O
2
< 20 mg/Nm
3
No
x
@ 13% O
2
104 mg/Nm
3
Efficiency 82 %
Nominel output 6 kW
Chimney temperature EN 13240 °C
Temperature in connecting piece 300 °C
Amount of smoke 5 g/sek
Sub-pressure EN 13240 12 Pa
Recommended sub-pressure in connecting piece 15 - 18 Pa
Required combustion air supply 13,3 Nm
3
/h
Fuel Wood
Fuel consumption 2 kg/h
Amount of fuel 1,5 kg
Technical data and dimensions
Materials: ...................................... Steel plate, cast iron, galvanised sheet,
vermicolite
Surface treatment: ........................................................................... Senotherm
Max. wood length: ..................................................................................... 30 cm
Weight Scan 64-1 and Scan 64-2: .................................................... ca. 123 kg
Weight Scan 64-3: ..................................................................................... ca. 180
Weight Scan 64-4: ............................................................................... ca. 168 kg
Weight Scan 64-5 and Scan 64-6: .................................................... ca. 117 kg
Connecting piece internal diameter: ............................................... 144 mm
Connecting piece external diameter: .............................................. 148 mm
Approval type: ................................................................ Intermittent fuelling
Intermittent fuelling means normal use of a woodstove. In other
words, you should let the fire die down until only the embers are left,
before refuelling.
The Scan 64 - series was build in compliance with the homologized
product type specified in the Assembly- and Instructions Manual
provided with the product.
The EC declaration of conformity is available from www.scan.dk
Scan 64-2, Scan 64-4 and Scan 64-6 Technical data Unit
CO Emission at 13% O
2
0,1 %
CO Emission at 13% O
2
1213 mg/Nm
3
Dust @ 13% O
2
< 20 mg/Nm
3
No
x
@ 13% O
2
117 mg/Nm
3
Efficiency 79 %
Nominel output 6 kW
Chimney temperature EN 13240 °C
Temperature in connecting piece 305 °C
Amount of smoke 6 g/sek
Sub-pressure EN 13240 12 Pa
Recommended sub-pressure in connecting piece 15 - 18 Pa
Required combustion air supply 12,5 Nm
3
/h
Fuel Wood
Fuel consumption 2 kg/h
Amount of fuel 1,5 kg
Test in compliance with EN 13240
