ASSEMBLY8
Remove packaging
Check that the stove is not damaged before installing it.
Scan 64 is supplied attached to a wooden pallet. Remove the two
screws from the wood compartment store, as illustrated below, and
lift the stove off the wooden pallet.
Scan 64-5 and Scan 64-6:
We recommend that you leave the protective film on the side plates
until the fitting is complete.
Screws to be removed
Remove the screws that securing the stove to the pallet.
Fit the plastic plugs from the service box into the transport protection
holes.
A
A
Remove the protection between the baffle plates, before taking the
stove into use!
Protection for baffle plates
Put back the upper plate on the pins, as the protection pushes the
plate upwards.
Pin for baffle plate
