SCAN 64 Series - Positioning Your Wood-Burning Stove; Distance to Furniture; Distance to Flammable Materials, Shown with Insulated Flue Pipe

ASSEMBLY9
2
1
0
0
Distance to flammable materials, shown with insulated flue pipe
Positioning your wood-burning stove
The wood-burning stove must be set up so that the stove itself, the
flue pipe, and the chimney can all be cleaned.
Distance to furniture: 1000 mm
But please check to avoid furniture or other furnishings being dried
out due to being too close to the stove.
5
0
2
4
2
500
747
5
3
7
2
5
0
5
1
5
250
7
8
2
Parallel rear wall installation
45° Corner installation
Scan 64-2, Scan 64-4 and Scan 64-6 (with side windows)Scan 64-1, Scan 64-3 and Scan 64-5 (without side windows)
5
0
2
4
2
350
5
0
50
3
1
5
5
8
2
2
5
4
597
Parallel rear wall installation
45° Corner installation
All national and local requirements concerning safety distances for
wood burning stoves must be respected.
If you connect the stove to a steel chimney, the safety distances of the
steel chimney must also be respected.
Flammable material
Installation:
The distances presuppose the use of an insulated flue pipe with min. 30 insulation all the way to the stove.
