Component identification
Component identification
1. Engine data plate
2. EGR valve
3. Exhaust brake
4. Actuator
5. Turbocharger
6. EGR cooler
7. Oil cooler
8. Oil filter
9. Engine serial number on the cylinder
block
10. Coolant pump
11. Draining coolant
12. Centrifugal oil cleaner
13. Oil filler
14. Engine control unit
15. Water separating prefilter for fuel
16. Hand pump for fuel
17. Fuel filter
18. Starter motor
19. Oil dipstick
20. Oil plug
336 872
1
2 3 4 5 6 7 8 9
10
11
12 13
14
15 16 17 13
18
1920
The illustration shows a normal version of a DC13 engine. The engine ordered may have different equipment
