Users / service manual for Scanomat TopBrewer Pro
Installation:
Table layout (top wiev):
The following installations must be provided
Electrical single
phase (optional)
(optional)
230-240 VAC Single phase,
50 Hz, with ground
connection, 6500- 7000 W,
28-30 Amp
10 Amp. (priority heating*)
3 Phase
(standard)
400 VAC 3 phase with neutral
and ground connection, 7000
W, 10 Amp.
Water Inlet
Pressure 2-6 bar, 200-600
kPa.
Flow rate min. 5l./min.
Temperature 5-12 °C
Tabl e
See diagram below
