4 Basic Operation Process
This chapter focuses on the mode selection of the KSCAN series, the
photogrammetry operation flow and the scanning operation flow.
4.1 Mode Selection
The KSCAN series of composite 3D scanners are equipped with red and blue
two-color laser and photogrammetry system modules, including global
photogrammetry, red light fast scanning and blue light fine scanning. Please
select the appropriate working mode according to the measured object (refer to
Table 4-1).
Table4- 1
Name
Mode
Object Size
Resolution
Accuracy
Glopho(GL)
Photogrammetry
Medium and large
workpiece
measurement
/
0.02mm+0.0
25mm/m
ScanViewer(SV)
Blue light fast
scan
Medium and large
workpiece
scanning
0.050mm
0.02mm+0.0
35mm/m
ScanViewer(SV)
Blue light fine
scan
Large workpiece
with small
features
0.010mm
0.01mm+0.0
35mm/m
ScanViewer(SV)
Infrared scan
Medium and large
workpiece
scanning
> 1.0mm
0.02mm+0.0
35mm/m
ScanViewer(SV)
Deep hole
workpiece with
special features
/
0.02mm+0.0
35mm/m
