72 Appendices
APPENDIX I TECHNICAL SPECIFICATIONS
Electrical
Power supply
voltage
100-240 VAC 50/60 Hz through external PSU (adapter) or
Power over Ethernet complying IEEE 802.3af (optional)
Power
consumption
3.25 Watt (5Vdc, 650 mA). At nominal configuration:
Omni laser scanner and Ethernet interface. USB port unused.
Shuttle
C
DC input +5 V
Interfaces Standard Ethernet, Wireless IEEE 802.11 a/b/g/n/ac (optional)
or Power over Ethernet IEEE 802.3af POE (optional)
Scanner characteristics
Light source Visible laser diode (630 – 670 nm) or red LED
Depth of field 200 mm (= maximum reading distance)
Scan pattern Omnidirectional laser pattern, single line CCD or 2D Imager
Bar code types
*Omni Directional Laser Scanner:
EAN/UPC/JAN+Add-on, ISBN, Code 128, EAN128, Code 93,
Code39, Code32, Codabar, Interleaved 2 of 5, MSI-Plessey
and GS1 DataBar.
*Single Line CCD Scanner:
All UPC/EAN/JAN, EAN128 Code, Code 39, Code 39 Full
ASCII Code32 / Italian Pharmacy, Code 128,
CODABAR/NW7,Interleaved 2 of 5, Industrial 25, Matrix 25,
MSI/PLESSEY, Telepen, Code 93, Code 11, China Postage,
Code 26, LCD25 and GS1 DataBar Family.
*2D Imager:
1D Symbologies:EAN/UPC,Australian Post, Aztec, BPO,
Canada Post, Dutch Post, EAN.UCC Composite, Interleaved 2 of
5, Japan Post, MSI Code, Planet, Plessey Code, Postnet, GS1
Databar, Standard 2 of 5, Telepen, TLC39 2D Symbologies:
Datamatrix, Matrix 2 of 5, Maxi 2 of 5, Maxicode and QR code
Physical
Dimensions 182 (h) x 131 (w) x 95 (d) mm
Display TFT-LCD Size 3.5’’ diagonal 320X240 pixels QVGA
70 X 53 mm
Color depth 16.7M Colors
450 nits High brightness Wide viewing angle
Housing PC/ABS
