18
MON 100
Schaeffler Technologies
High precision bearings for combined loads
All the fixing screw holes must be used. If a smaller number of
fixing screws is used, this will reduce the load carrying capacity of
the screw connections as well as the running accuracy and rigidity of
the bearing.
The rigidity values in the dimension tables of TPI 120, High Precision
Bearings for Combined Loads, and in Catalogue HR 1, Rolling
Bearings, are only valid if all the fixing holes are used.
In order to prevent unacceptable variations between the screw
tensioning forces, adhere exactly to the fixing sequence (tighten
the screws in a crosswise sequence).
Tightening torques M
A
for
axial/radial bearings
1)
Tightening torque M
A
for fixing screws to DIN EN ISO 4762, grade 10.9.
Bore
diameter
Fixing screw Tightening torque
1)
M
A
Nm
Stage
1 2 3
mm 40% of M
A
70% of M
A
100% of M
A
50 M5 3 6 8,5
80 M4 3 3 4,5
80 M5 3 6 8,5
100 M5 3 6 8,5
120 M6 6 10 14
150 M6 6 10 14
180 M6 6 10 14
200 M6 6 10 14
260 M8 14 24 34
325 M8 14 24 34
395 M8 14 24 34
460 M8 14 24 34
580 M10 27 48 68
650 M12 46 81 116
850 M16 114 199 284
950 M16 114 199 284
1030 M16 114 199 284
