Operating Instructions Caravan-charging system CSV 416
13
Date: 30.05.2021
8050111 BA / EN
RemedyPossible causeFault
Pump does not switch on
when a water tap is
opened.
Pump supply not switched
on from control panel
Switch on the pump sup-
ply (refer to the operating
instructions for the rele-
vant control panel)
Fuse blown Replace the fuse
Water tap switch or ca-
bling for water tap defec-
tive
Contact customer service
Pump supply not switched
on from control panel
Switch on the pump sup-
ply (refer to the operating
instructions for the rele-
vant control panel)
Y The charging current is reduced automatically if the device becomes too
hot due to excessive ambient temperature or lack of ventilation. Always
prevent the device from overheating nevertheless.
5.2 Shutting down t h e system
" Switch off the main 12V switch on the control panel connected.
5.3 Shutting down t h e system
Y ATTENTION!
Total discharge causes damage to the caravan battery. So therefore:
F Fully charge the caravan battery before and after closing down the
system. Connect a vehicle with an 80 Ah battery and a vehicle with a
160 Ah battery to the mains for at least 24 and 36 hours respectively.
The caravan battery is then protected against total discharge. This only
applies if the battery is intact. Follow the battery manufacturer’s instructions.
Y ATTENTION!
Connected consumers can be damaged on exceeding the input voltages
permitted. So therefore:
F Do not operate any connected Schaudt LR ... solar charge regulator
without battery.
F When the battery is replaced or removed, unplug the ”Caravan bat-
tery” connector on the CSV 416A beforehand (or unplug the ”+ Solar
cell” connector on the solar charge regulator).
" Unplug the ”Solar charge regulator” connector on the CSV 416A (or
unplug the ”+ Solar cell” connector on the solar charge regulator).
" Unplug the ”Caravan battery” connector on the CSV 416A (or remove the
clamps from the battery terminals).
