Operating Instructions Caravan-charging system CSV 416
5
Date: 30.05.2021
8050111 BA / EN
3.2 Switching on and off
Control and switch panels must be supplied with a separate operating ma-
nual (kept with the vehicle). Please refer to this manual for instructions on
operation.
Activating the 12V main switch (12V ON) on the operating panel connected
enables/disables the following electrical circuits:
Pos.
Circuit Fuse with
1 Heater 10 A -- With the mains supply, there is no switch-off
by the main 12V switch
2 Pump/WC 10 A -- Can be enabled individually over the bus
3 Circuit 1 15 A -- Can be enabled individually over the bus
4 Circuit 2 15 A -- Can be enabled individually over the bus
5 Circuit 3 15 A
6 Awning light
10 A7 TV
8 Spare
5 Circuit 4 15 A
5 Circuit 5 10 A
Outputs
F switching output 1
F switching output 2
F switching output N
can only be enabled over the bus, regardless of whether the main 12V
switch (12V ON) is switched on or off.
3.3 Changing the battery
Y ATTENTION!
The use of incorrect battery types or incorrectly designed batteries can
damage the battery itself or devices connected to the caravan charging
system. So therefore:
F Batteries may only be changed by qualified personnel.
F Follow the battery manufacturer’s instructions.
F The caravan charging system is only suited for connecting to 12V
power supplies with chargeable batteries (of the types specified be-
low).
F Do not use non-approved battery types such as NiMH batteries.
Y Normally only batteries of the same type and capacity should be used,
i.e. the same as those installed by the manufacturer .
It is possible to swap from lead-acid batteries to other battery types.
Switching to lead-acid batteries is only possible in certain circumstances.
Contact the vehicle manufacturer for more information.
