 I (”Bulk”)
Main charge with maximum 20 A charging current, electronically limited, up
to end-of-charge voltage U
VL
. Start of charge also for completely discharged
batteries.
 Uo (”Absorption”)
Automatic switchover to full charging with constant voltage U
VL
. The dura-
tion of the full charge phase is based on the battery type (is set from an EBL
... control panel connected). This sets a full charge time and minimal charge
current.
 U (”Float”)
Automatic switchover to trickle charging with constant U
EL
. In the trickle
charge phase, a constant voltage is applied to the charger module output.
 U (”Standby”)
Further reduction of charge voltage to U
R
. This phase lasts time t
R
.
 U (”Refresh”)
A refresh with full charge voltage U
VL
for time t
F
is started once idle phase
time t
R
has expired.
Y All voltages and times are dependent on the battery type used. These
parameters are set automatically by setting the correct battery type:
Phase 1 Phase 2 Phase 3 Phase 4 Phase 5
I (”Bulk”) Uo (”Absorption”) U (”Float”) U (”Standby”) U (”Refresh”)
Battery
type
I
max
U
VL
t
VL
U
EL
t
EL
U
R
t
R
t
F
Lead-acid 28 A 14.40 V 4 hour 13.40 V 72 hour 13.00 V 120 hour 1 hour
Lead-gel/A
GM1
28 A 14.40 V 8 hour 13.80 V 72 hour 13.20 V 120 hour 1 hour
AGM 2 28 A 14.70 V 4 hour 13.70 V 72 hour 13.20 V 120 hour 1 hour
LiFePo4* 28 A 14.40 V 2 hour 13.80 V
contin-uo
us
-- -- --
* Only batteries with their own battery management system fitted may be
used.
6.3 Environmental parameters
-20 Cto+45C
-20 Cto+70C
IP 20
Operation in dry environment only
CE mark
7 Maintenance
The CSV 416A caravan charging system requires no maintenance.
Clean the caravan charging system using a soft, slightly damp cloth and mild
detergent. Never use spirit, thinners or similar substances. Do not allow fluid
to ingress the caravan charging syst em.
