Instruction Manual for Electrobloc EBL 262-4
3
Date: 08.07.2019
8110265 BA / EN
2 Introduction
This instruction manual contains important information for safe operation of
the device. Make sure you read and follow the safety instructions provided.
The instruction manual should be kept in the vehicle at all times. Ensure that
other users are made aware of the safety regulations.
3 Operation
The electrobloc is operated exclusively by the IT .../LT ... control and
switching panel connected.
Operation of the EBL 262-4 electrobloc is not required for daily use.
Settings only have to be configured once if the battery type is changed
(lead-acid or lead-gel), during initial start-up or when retrofitting accessories
(see section 3.2 and installation instructions for EBL 262-4).
3.1 Star ting up the system
Y ATTENTION!
Incorrect electrobloc settings.
Damage to connected devices. Therefore prior to starting:
F Ensure the leisure battery is connected.
F Make sure the battery selector switch (fig. 3, pos. 5) is set to the cor-
rect position for the battery inserted.
Use the 12 V main switch (see instruction manual of relevant control and
switch panel) to switch on/off all the consumers and the control and switch
panel.
The outputs are exceptions:
F Circuit 1/Refrigerator control
F Heater
F Additional heater (50 W)
F Step
F Awning light
F Refrigerator
These outputs are not disabled by the main switch of the IT .../LT ... control
and display panel.
For further information, see operating instructions of the IT .../LT ... control
and switch panel.
