Schenker WIKI User Manual

4 –OPERATION REV.02
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia - ALL RIGHTS RESERVED
17
4.3 Electric connections
The 12/24 V power supply, from the service batteries, must be connected to the provided plug. A 16 Ampere
automatic circuit breaker for 12V systems must be installed on the power supply, while a 10 Ampere for 24V
systems.
The connection must be suitable to take the typical electric load (110-150Watt continuous)
The power supply cable section is related to the length of the cable.
The maximum length of the cables for 12V systems is 4 meters (4 meters for the positive + 4 meters for the
negative)
Voltage
Breaker
Cable length 4m
Volt
Ampere
mm2
AWG
12
16
10
7
24
10
4
11
