Schenker ZEN 100 User Manual

3 – PRESENTATION OF THE PRODUCT COD.30Z12/24.B.2021
3 – PRODUCT PRESENTATION COD: 150Z24.B.2021
THE PRESENT MANUAL BELONGS TO - Schenker Italia - ALL RIGHTS RESERVED
11
Weight 46,1 Kg (empty)
Hydraulic Connection
Seawater inlet: hose barb for 20mm internal diameter reinforced hose.
Brine Discharge: hose barb for 16mm internal diameter reinforced hose.
Fresh water: ¼’’ fitting, 6x8mm hose.
PUMP
Dimensions
Length: 42 cm
Width: 15 cm
Height: 23 cm
Weight: 14,3 Kg
Hydraulic Connection
Water inlet: hose barb for 20mm internal diameter reinforced hose.
Water outlet: hose barb for 16mm internal diameter reinforced hose.
Feed pump type: Rotative pump
Filters: n. 1 Cartridge filter 5 microns 2.32" x 9 ¾’’
n. 1 Active carbon filter 2.32" x 9 ¾’’
Power supply: 24 VDC +/- 15% (150Z24 version)
Average electric consumption: 600 Wh average
Nominal fresh water production: 150 Lit/h +/- 20% @ seawater 25 °C salinity 35.000 ppm
CEE conformity: In compliance with directives 89/392 CEE sect.1 (general safety machines
requirements), 89/336 CEE (electromagnetic compatibility), 73/23 CEE
(electric safety requirements)
3.6 Features of the product
The fresh water produced by a Schenker watermaker, obtained by clean seawater, has a high purity. Despite
this, the potability may not be guaranteed: bacterium caused by non-observance of shutdown and cleaning
procedures may be present in the watermaker. Therefore, it is essential that the correct shut down and storage
procedures are followed to ensure continued purity of the fresh water. UV treatment of the fresh water may
well be beneficial.
