Even when the device is being used properly, there will
always be certain residual hazards that cannot be com-
pletely ruled out. The following potential hazards can
arise due to the type and design of the device:
• Unintentional starting up of the product.
• Damage to hearing if the stipulated hearing protec-
tion is not worn.
• Dirt particles, dust etc. can get into the eyes or face
despite wearing safety goggles.
• Inhaling swirled up particles.
8. Unpacking
m ATTENTION!
The device and packaging materials are not toys!
Children must not be allowed to play with plastic
bags, lm and small parts! There is a risk of swal-
lowing and suocation!
• Open the packaging and remove the device care-
fully.
• Remove the packaging material as well as the pack-
aging and transport bracing (if available).
• Check that the delivery is complete.
• Check the device and accessory parts for trans-
port damage.
• If possible, store the packaging until the warranty
period has expired.
9. Before starting the equipment
• Before you connect the equipment to the mains sup-
ply make sure that the data on the rating plate are
identical to the mains data.
• Check the equipment for damage which may have
occurred in transit. Report any damage immediately
to the transport company which was used to deliver
the compressor.
• Install the compressor near the point of consumption.
• Avoid long air lines and supply lines (extension ca-
bles).
• Make sure that the intake air is dry and dustfree.
• Do not install the compressor in a damp or wet room.
• The compressor may only be used in suitable rooms
(with good ventilation and an ambient temperature
from +5 °C to 40 °C). There must be no dust, acids,
vapors, explosive gases or inammable gases in the
room.
• The compressor is designed to be used in dry
rooms. It is prohibited to use the compressor in are-
as where work is conducted with sprayed water.
6. Technical data
AC mains power connection 220-240 V~ 50 Hz
DC connection 12 V
Motor rating W max. 150
Operating mode*
S3 25%
Compressor speed
4200 min
-1
Operating pressure
ca. 8 bar
Theoretical intake capacity
l/min
ca. 36,5
Eective output rate at 1 bar ca. 18 l/min
Protection type
IP30
Protection class
II
Weight in kg
1,6
AC cable length 1,8 m
DC cable length 4 m
Hose length 600 mm
Subject to technical modications!
*S3 25% = periodical intermediate duty with a duty cy-
cle of 25% (2.5 min based on a 10 minute period)
The noise emission values were measured in accord-
ance with EN ISO 3744.
Wear hearing protection.
The eects of noise can cause a loss of hearing.
Noise data
m Warning: Noise can have serious eects on your
health. If the machine noise exceeds 85 dB, please
wear suitable hearing protection.
Sound power level
L
wA
90 dB
Sound pressure level L
pA
75,9 dB
Uncertainty K
wA/pA
2,36 / 3 dB
7. Residual risks
Comply with the stipulated maintenance and safety in-
structions in the operating instructions. Remain atten-
tive at all times when working and keep third parties at
a safe distance from your work area.
