Scheppach CSP50 User Manual

 www.scheppach.com
GB
|
37
• Now thoroughly clean the entire chain drive area
and the chain cover (22) with a brush or by blowing
it out (with compressed air).
The re-assembly takes place in reverse order.
13.4 Maintenance of the spark plug
• Remove the air lter (33) as described in 13.2
“Cleaning the air lter”.
• Remove the spark plug connector (33) by turning it
to the left and right and pulling it at the same time.
Hold and pull the spark plug connector (33) by the
connector only. Never pull on the cable! (See g. O)
• Loosen the spark plug with the enclosed spark plug
wrench / slotted screwdriver (28).
• The re-assembly takes place in reverse order.
Electrode gap = 0.6 mm (distance between the elec-
trodes, between which the ignition spark is generat-
ed). Check the spark plug for dirt and grime after 10
operating hours and if necessary, clean it with a cop-
per wire brush.
Then service the spark plug every 50 operating hours.
13.5 Maintenance of the chain lubrication
• See chapter “Checking and adjusting chain lubrica-
tion”.
13.6 Maintenance of the carburettor settings
• If the saw chain (17) moves at idle or the engine
stops by itself when the throttle is released, a car-
burettor adjustment must be made.
Note
Have carburettor adjustments (e.g. idle speed) carried
out only by qualied specialists to avoid engine dam-
age.
13.7 Maintenance of the guide bar
• Remove any burrs on the edge of the guide bar us-
ing a metal le.
• Clean the groove of the guide bar (16) using a brush
or compressed air. Replace the guide bar (16) as
soon as the groove is worn.
• Turn the guide bar (16) after each use to ensure
even wear.
• Check the sprocket at the tip of the guide bar (16)
for smooth running. If necessary, lubricate it with a
bearing oil.
13.8 Mounting the guide bar and tensioning the
saw chain
m ATTENTION
Always carry out assembly with the engine switched
o󰀨.
13.1 Cleaning the engine unit
m WARNING
Danger of burning!
Do not touch hot silencers, cylinders or cooling ns.
• Keep protective devices, air vents and the engine
housing as free of dust and dirt as possible. Blow it
out with low-pressure compressed air.
• Clean the device at regular intervals using a damp
cloth and a little detergent. Make sure that no water
can penetrate the device interior.
13.2 Cleaning the air lter
Fouled air lters diminish the engine output due to re-
duced air supply to the carburettor.
Regular inspection is therefore essential. The air l-
ter (32) should be checked regularly and cleaned as
required.
The air lter (32) must be checked more frequently in
the case of very dusty air.
• Loosen the catch for the air lter cover (5) by turning
it anti-clockwise. (See g. M)
• Remove the air lter cover (3).
• Remove the air lter (32). (See g. N)
• Clean the air lter (32) by knocking out or blowing
out (with compressed air).
The re-assembly takes place in reverse order.
m ATTENTION
Never clean the air lter (32) with petrol or ammable
solvents.
13.3 Cleaning the chain drive
m WARNING
Risk of injury!
Always wear protective gloves when touching the saw
chain (17). Danger of injury due to the sharp cutting
teeth!
Note
Clean the chain drive after each use.
• Set the chainsaw down on a level and stable sur-
face.
• Pull the front hand guard (1) back as far as it will go
to release the chain brake (see g. B).
• Remove the two xing nuts (20) with the spark plug
wrench / slotted screwdriver (28).
• Remove the chain cover (22).
• Carefully remove the saw chain (17) from the guide
bar (16) and the chain wheel (26).
• Remove the guide bar (16). Clean them with a
brush.
